Monday, June 7, 2010

Monome

Unsped shields came a few weeks back from a monome forum group buy,

ready to link up to an arduino that i still need to buy....

will have all components ready to solder on soon.


also picked up a PCB for a Tubescreamer guitar pedal clone from tonepad website

some great stuff there, pics up soonish. :)

Wednesday, April 21, 2010

hmmm

wow, it's been awhile..

Have not made that much progress on the midi controller, i have basically gone back to my original plan of direct wire.

So far i have 4 working faders, and 8 working knobs in daisy chains.

I will post pics when i can.

As for the arduino, i am still waiting on confirmation of shipping for it to get down under!!

stay cool!

Wednesday, March 31, 2010

step backward...

found out the very disappointing and hard way that my joysticks are on the fritz, going to have to 'buy' some instead of salvaging...

and another discovery, for some reason, hooking things up to the breakout board is not registering on the brain, so, by the looks of it, im going to be doing this project the hard way, because i just want to push ahead and get things done, i will have a new faceplate design up soon..... without joysticks. :(

NEVER fear i will be doing another project after i finish the monome, probably some kind of pocket midi effects or something using joystick and knobs etc really small.

btw, im building a monome with arduino, got most of the parts ready, this is going to be a full day thing, done in a day, hopefully.


Cheers!

Tuesday, March 30, 2010

Joystick Wiring 2/3

Been a long few days, but I finally got around to attaching these bad boys up to the breakout board.

as promised i will explain the daisy chain...

Each component needs a voltage and a ground. you can grab these from anywhere you like on any circuit at any time. you can also daisy chain them, because they are constant, you can spread them instead of connecting a voltage and a ground from the source to each individual component we just daisy chain the source to multiple components and save on the spaghetti!! super duper easy!

Now, connecting our supermegaultraawesome joysticks up to the breakout...

Really simple.

Get your 4 signal cables and use the schematic in 1/3, connect the cables to their own JP3. DONE! so easy! i use bits of blu-tack to hold them in place when i flip the board over to solder!



Now connect your ground cable to JP1 to ANY JP1 hole in the corresponding column and the voltage to JP2. thats it! really simple.



Chuck a pin header (10 pins) where it should be done at the bottom and your ready for part 3/3 hooking up to the brain and programming them in, coming VERY SOON!!!!

Cheers!


Wednesday, March 24, 2010

Joystick Wiring 1/3

Let's jump straight in, I've got my Livid Breakout board, my joysticks and my initiative!!

Below i have made a schematic for how the joysticks are to be wired to the potentiometer section of the breakout Board. I am also using sparkfun joystick breakouts.




As you can see, each joystick has 2 signal cables, one vertical (X) and one horizontal (Y)

The way i have wired the voltage and ground is in a daisy chain. i will explain this a little bit more in part 2/3. but for now we will just be doing some practical.

Below is some wire that i ripped out of an old PC i had laying around. this is just the HDD light cable that goes from the front bezel to the motherboard. good colours for what i want to demonstrate. red is our voltage and white is the ground, they are also pre-twisted so its not as messy!

Cut a small amount for the end so you have 2 of each colour one large and one small.

Strip these and twist together like the picture.

We now have a simple one-step daisy chain!

If you want more just add multiple little pieces of wire like a necklace.



Now, with your vice or helping hands, put the first voltage and ground wire into your joystick breakout and solder. hopefully you have a better quality soldering iron than me :(


Now find your Signal Cables, i have decided to use orange! because it rhymes with nothing! solder these connections. NOTE* if you have these joystick breakout boards, you may notice a hole called "sel" this is the signal for the built in selector switch, i have decided that its not relevant, but i am sure that it could be hooked up somehow if needs be, but would involve using the button matrix and adding voltage and ground wires.

What you want to do now is get your small daisy chain wires and hook up the voltage and ground to the second joystick, then add the signal cable, and you should have something like what i have below.



Stay tuned.... in part 2/3 i will be explaining our daisy chain and hooking up the the breakout board!

Cheers!

Tuesday, March 23, 2010

Parts Update

Last few days have seen some exciting deliveries.

and some very good customer service, and some bad

My faders arrived from farnell.com.au in very good time and a very professional packaging, no spare on bubblewrap, which is GREAT makes sure my parts are secure and i have something else to play with.
I ended up ordering breakout boards for the PS2 joysticks, to make my soldering life easier and so i could mount them nicely, while i was on their site i ordered a WII chuk adapter/breakout for my future ardrino projects, and also got a rotary encoder to experiment making a jog-wheel for the Livid brain. all these bits came from littlebirdelectronics.com.au. little bird has fantastic customer service, answered all my question promptly, even on weekends! and gave a handwritten thankyou note to me. just great!

although, im still waiting on my rotary pots and switches from futurelec.com.au which were ordered on the same day as the other parts, i have also waited a week for a quote on my arduino monome shield.... :(


Saturday, March 20, 2010

Midi Controller: Thumb Sticks

So as i have been staying up late at night obsessing over electronics and this controller, i have found that i have an old PS2 (not working) in the cupboard (totally unrelated you say?? i think not).

These PS2 controllers have 2 analog thumb joy sticks in them. these joysticks are 2 axis, X and Y, up/down and left/right, basically 2 rotary potentiometers per joystick package.

To explain this a bit more....

1 rotary potentiometer has 3 pins, a ground (-) a voltage (+) and a Signal.

The joystick has 3 pins per each axis, so 6 pins, easy as pie to wire up.

The thing im really excited about is that i can assign 2 MIDI parameters per thumbstick.

So, 4 effects, 4 sends, 4 pans etc all at the same time.

Today I busted the PS2 controller open and salvaged the joysticks!!
(its very easy when you get a solder sucker, just google "solder removal" for more info)

I will be using Breakout Boards for mounting and connecting these, if you would like a breakout board or you just want to buy the thumbsticks and not the PS2 controller they are available at:

US/international: www.sparkfun.com

Australia: www.littlebirdelectronics.com

Still waiting for my other parts.. so this keeps me out of trouble... for now.

Cheers!

here are some pics:
